UTG Pro - M-LOK Tactical Flashlight Mount for MP5 - Aluminum - Black - MTU058SSM
Mounting rail for tactical weapon lights in the M-LOK system mounted on the MP5 platform. UTG's Pro series has prepared an all-aluminum accessory that allows you to adapt the front space to the corresponding weapon flashlights. Mounting the adapter on the weapon is done by screwing a crossbar with screws to the rail plugged around the musket of the mechanical sight.
The correct functioning of this rail is made possible by the manufacture of precision-milled 6061-T6 aluminum. Parts machined in this way are characterized by a tight fit with the factory MP5 platform sight. The user is provided with a total of five and a half standard M-LOK system holes. Two and a half are located on the top rail, one on the left and two on the right side at a 45° angle.
Once attached, the rail does not interfere with other components on the MP5, both stationary ones like the front bed and moving ones like the reloading handle. The patented design weighs less than 50 grams, so it won't add much weight to a platform intended to be lightweight. A total of three screws, which can be treated with thread glue, are responsible for securing the rail mount.
Features:
- Aluminum rail for mounting tactical flashlights on the MP5
- Compatible with the MP5 platform except for the K series
- Five full-length and one shorter M-LOK mounting hole
- Available side mounting holes at a 45° angle
- Precision milled from 6061-T6 aluminum
- Low own weight
- Screw threads can be secured with specialized adhesive
- Does not interfere with other factory MP5 components
| Technical specifications | |
|---|---|
| Compatibility | MP5 platform excluding K series |
| Mounting | M-LOK |
| M-LOK mounting holes | Top: 2 full and 1 halfLeft 45°: 1 fullRight 45°: 2 full |
| Patent number | US PAT. 12281873 |
| Torque of screws | T10: 1.65 Nm1/16 Hex: 1.1 Nm |
| Dimensions | 123 x 40 x 17 mm |
| Material | Aluminum 6061-T6 |
| Weight | 45 g |
| Color | Black |
