Vector Optics - Rifle Scope Minotaur 4-16x50 GenII - SFP - SCOL-38
Vector Optics - Rifle Scope Minotaur 4-16x50 GenII - SFP - SCOL-38
The Minotaur GenII spotting scope is equipped with a fixed magnification of 46x and a 60mm objective lens. The VETD-LR sighting reticle on the SCOL-38 has been placed in the second focal plane (SFP), which allows it to maintain a constant size regardless of viewing conditions. The red illumination operates at eleven brightness levels, including one adjusted for night vision operation.
The turret adjustment range is +/-40 MOA vertically and horizontally, with clicks of 1/8 MOA. The vertical turret is equipped with a zero-stop function, and the horizontal turret has a rotation lock. The parallax is laterally adjustable from 9m to eliminate aiming errors at various distances. Diopter correction from +2 to -2 allows the scope to be adjusted to the individual needs of a user with a visual impairment.
The optics are enclosed in a 34 mm barrel made of anodized 6061-T6 aluminum, filled with nitrogen gas. The design provides resistance to water splash (IPX4) and shock up to 1000 G. The fully multi-coated (FMC) optical coating improves light transmission and reduces glare. The spotting scope is powered by a single CR2032 battery, located under the on/off button. High profile mounting rings for Picatinny rail are included.
Features:
- Fixed 46x magnification suitable for long range shooting
- 34mm tube made of 6061-T6 aluminum with nitrogen filling
- Targeting reticle located behind the magnification system
- VETD-LR reticle with illumination in 11 levels (including 1 night level)
- Turrets with 1/8 MOA clique value and zero-stop function
- FMC optics for high transmission and clear images
| Technical specifications | |
|---|---|
| Magnification | 46x |
| Type of target reticle | VETD-LR |
| Aiming reticle position | SFP |
| Objective diameter | 60 mm |
| Diopter correction | +/- 2 |
| Optical coating | Multilayer coating (FMC) |
| Field of view (at 100 m) | 0,91 m |
| Distance from the eye | 96-95 mm |
| Tube diameter | 34 mm |
| Click value | 1/8 MOA |
| Vertical adjustment range (at 100 m) | +/-40 MOA |
| Horizontal adjustment range (at 100 m) | +/-40 MOA |
| Backlight adjustment | 10 levels 1 night mode |
| Power supply | CR2032 battery |
| Shock resistance | 1000 G |
| Protection class | IPX4 |
| Length | 431 mm |
| Material | Aluminum 6061 T6 |
| Weight | 945 g |
| Color | Black |
Kit components:
- Scope
- Picatinnny 34mm mounting rings
- Sunshield
- Flip-up lens covers
- Allen wrench
- Lens cleaning cloth
